威綸通新品發布——MT8000 Series
http://www.debgrams.com 2006-11-21 09:16 來源：中華工控網
MT8000產品規格一覽
機型 |
MT8121T |
MT8104T |
MT8080T | |
|
|
|
|
| |
|
認證 |
CE / UL |
CE |
CE | |
|
顯示器 |
12.1" TFT |
10.4" TFT |
8" TFT | |
|
背光 |
250 cd/m2 |
400 cd/m2 |
400 cd/m2 | |
|
色彩 |
65536 color |
65536 color |
65536 color | |
|
對比 |
200:1 |
300:1 |
250:1 | |
|
分辨率 (WxH dots) |
800 x 600 |
640x480 |
640x480 | |
|
背光燈 |
CCFLx2 |
CCFLx2 |
CCFLx1 | |
|
背光燈壽命 (avg.) |
50,000 hr. |
50,000 hr. |
50,000 hr. | |
|
觸控屏 |
|
4 wires resistive type |
| |
|
觸控精準 |
|
2mm |
| |
|
觸控硬度 |
|
4H |
| |
|
串行端口接口 |
Com1(RS232/RS485 2w/4w), Com2(RS232), Com3(RS232/RS485 2w) | |||
|
以太網口接口 |
|
10/100 Base-T |
| |
|
USB 接口 |
|
USB 2.0 x 3 |
| |
|
音源輸出 |
Line Out x 1 |
| ||
|
處理器 |
|
32bit RISC CPU |
| |
|
內存 |
|
32MB |
| |
|
配方內存 |
|
Yes |
| |
|
CF 卡接口 |
|
Yes |
| |
|
萬年歷RTC |
|
Yes |
| |
|
系統診斷 |
|
Power failure detection |
| |
|
電壓 |
|
24 VDC ± 5% |
| |
|
消耗電流 |
500 mA@24VDC |
440 mA @ 24VDC |
440 mA @ 24VDC | |
|
外型尺寸WxHxD |
333x243x51mm |
286x212x55mm |
231x176x55mm | |
|
開孔尺寸 |
305 x 231 mm (12"x9.09") |
261 x 203 mm |
222 x 167 mm (8.7"x5.43") | |
|
重量 |
Approx.2.1 kg (4.63 lbs) |
Approx.2.0 kg |
Approx. 1.3 kg (2.87 lbs) | |
